Optokuplör modülü; gri Note:Optocouplers and solid state relays are designed for use in signal processing networks, which are not supplied by the low-voltage power supply networks.
Optokuplör modülü; gri
Note:
Optocouplers and solid state relays are designed for use in signal processing networks, which are not supplied by the low-voltage power supply networks.
| Nominal input voltage UN | DC 5 V |
| Input voltage range (low level) | DC 0 … 1 V |
| Input voltage range (high level) | DC 4 … 6,25 V |
| Nominal input current at UN | 7,7 mA |
| Circuit type | 2-conductor termination Zero-voltage switching |
| Limiting continuous current | 0,5 A |
| Çıkış tepe akımı | 30A |
| Nominal output voltage | AC 230 V |
| Output voltage range | AC 24 … 260 V (50 … 60 Hz) |
| Max. voltage drop at output | ≤ AC 1,2 V |
| Leakage current at nominal voltage | ≤ 1 mA |
| Min. switching current | 50 mA |
| Turn-on time | ≤ 10 ms |
| Drop-out time | ≤ 10 ms |
| Switching frequency | 50 Hz / 60 Hz |
| Durum göstergesi | LED red |
| Dielectric strength, control/load circuit (AC, 1 min) | 2,5 kVrms |
| Bağlantı teknolojisi | CAGE CLAMP® |
| Tek damarlı boylar | 0,08 … 2,5 mm² / 28 … 14 AWG |
| İnce bükümlü kablolar | 0,08 … 2,5 mm² / 28 … 14 AWG |
| Sıyırma uzunluğu | 5 … 6 mm / 0.2 … 0.24 inch |
| Width | 6 mm / 0.236 inch |
| DIN rayın üst kenarından yükseklik | 56 mm / 2.205 inch |
| Depth | 91 mm / 3.583 inch |
| Montaj tipi | DIN 35 ray |
| Renk | gri |
| Yangın yükü | 0,313MJ |
| Ağırlık | 20,4 |
| Surrounding air (operating) temperature at UN | -25 … 55 °C |
| Surrounding air (storage) temperature | -40 … 70 °C |
| Processing temperature | -25 … +50 °C |
| Standartlar/spesifikasyonlar | EN 61000-6-2; EN 61000-6-3; UL 508 |
| Product Group | 6 (Interface Electronics) |
| SAP´den ambalaj tipi | BOX |
| Country of origin | DE |
| GTIN | 4055143606738 |
| Customs Tariff No. | 85365005000 |
